Suitable gearboxes
Drive unit consisting of motor and gearbox
We offer a wide range of proprietary drive solutions consisting of a motor and gear unit. They are all based on the synchronous motors of the Rotek modular system and its components. It offers countless variation options. This allows us to configure the exact drive for you that is ideal for your application. However, you can also put together your own drive solution using our configurator.
We specialise in the production of geared motors in small and medium series. All motors have a diameter of 65 mm and the same external design. This means they can be combined with any component from this modular system.
Our gearboxes
Spur gearbox
max. torque 6 - 13 Nm
Gear ratios i = 5:1 - 1.333:1
Output shaft 8 - 12 mm
for motors up to 30 W
Planetary gearbox
Max. torque 3 - 50 Nm
Gear ratio i = 4:1 - 308:1
Output shaft 8 - 14 mm
for motors up to 100 W
Worm gearbox
max. torque 5 - 12 Nm
Gear ratios i = 2.5:1 - 100:1
Centre distance 31 mm
for motors up to 50 W (optional 100 W)
Our motors
Qualified
Would you like advice?
We help you professionally and in a solution-orientated manner.
