Details	Values
SPEED	400 - 4000 1/MIN
OUTPUT	8 - 200 W
DIAMETER	72 mm

UP TO

IP69K

IN DEVELOPMENT

200

WATT

STAINLESS STEEL MOTORS ROTECT

Uncompromising cleanliness thanks to hygienic design

Developed for the highest hygiene standards: The ROTECT consistently eliminates any dirt nests thanks to its extremely smooth surfaces made of 1.4404 stainless steel. Thanks to IP68 (10 bar) and IP69K protection, it permanently withstands aggressive cleaning processes and highly corrosive environments. Utilise the full modular flexibility: Combine the protective housing individually with the proven technology of ROBASE, ROSYNC or ROMOTION for your application in the food, pharmaceutical or chemical industry.

Technical details

Utilise the full flexibility of our modular system. The ROTECT housing guard can be individually combined with the ROBASE, ROSYNC, ROSLYDE or ROMOTION motor series to precisely fulfil your specific requirements. In combination with our planetary gearboxes, you can realise peak torques of up to 75 Nm in the smallest of installation spaces, even in hygienically demanding areas.

Properties

Housing made of stainless steel 1.4404
Hygienic design with smooth surfaces without dirt pockets
Protection class IP68 (10 bar) & IP69K
Resistant to high-pressure cleaning

Technology

Free choice: BLDC, AC or DC
Power up to 200 watts
Planetary gearbox up to 75 Nm
Compatible with all motor series
Compact design

Use

Food & beverage industry
Spray area (no product contact)
Chemical & pharmaceutical production
Offshore & marine technology
Temperature range: -25 °C to +40 °C

Compact, highly efficient and uncompromisingly robust: In combination with our planetary gearboxes (type P and R), drive units are created that transmit the highest forces in the smallest space. Thanks to lifetime lubrication, the gearbox is absolutely maintenance-free and designed for continuous use under load.

Advantages

High torque in a small installation space
High impact resistance
Very good efficiency

Properties

Concentric shaft output
Low gear backlash
Maintenance-free

Options

Low-noise versions
Special shafts and flanges
Special lubrications

General information
Gear wheels	Hardened steel with high load capacity
Shaft bearing	2 ball bearings positioned one behind the other
Lubrication	Lifetime greasing
Installation positions	any
RoHS, WEEE, REACH	✓
Operating limits
Gear backlash	max. 0.9° (R series: 2.0°)
Max. Radial/axial load
Type P	150 N / 50 N 1-stage
	250 N / 80 N 2-stage
	350 N / 110 N 3-stage
Type R	190 N / 50 N 1-stage
	280 N / 80 N 2-stage
	410 N / 110 N 3-stage

Output data: ROTECT with ROBASE (synchronous motor)

OUTPUT DATA STAINLESS STEEL MOTOR ROTECT WITH ROBASE 6-POLE

Translation of	Permissible torque (peak)		Speed	Torque of the motor types
i	Type P	Type R	1/min	36	46	66	86
i	Nm	Nm	1/min	Nm	Nm	Nm	Nm
Operating mode				S3 75 %	S3 50 %	S3 50 %	S3 33 %
1-stage η = 80 %
3,7	4 (6)	8 (12)	270,3	0,22	0,33	044	0,62
2-stage η = 75 %
13,7	12 (18)	25 (37)	73,0	0,77	1,13	1,54	2,16
25	12 (18)	25 (37)	40,0	1,41	2,06	2,81	3,94
3-stage η = 70 %
50,9	25 (37)	50 (75)	19,06	2,67	3,92	5,34	7,48
58,9			17,0	3,09	4,54	6,18	8,66
68,1			14,7	3,58	5,24	7,15	10,01
92,7			10,8	4,87	7,14	9,73	13,63
107,2			9,3	5,63	8,25	11,26	15,76
129,6			7,7	6,80	9,98	13,61	19,05
168,9			5,9	8,87	13,01	17,73	24,83
236,1			4,2	12,40	18,18	24,79	34,71
307,6			3,3	16,15	23,69	32,30	45,22

Depending on the application, a higher operating mode is also possible. If the permissible torque is exceeded, the gearbox may be damaged. Three-phase versions offer approx. 10-30 % more torque. Other ratios available on request.

OUTPUT DATA STAINLESS STEEL MOTOR ROTECT WITH ROBASE 4-POLE

Translation of	Permissible torque (peak)		Speed	Torque of the motor types
i	Type P	Type R	1/min	36	46	66	86
i	Nm	Nm	1/min	Nm	Nm	Nm	Nm
Operating mode				S3 75 %	S3 50 %	S3 50 %	S3 33 %
1-stage η = 80 %
3,7	4 (6)	8 (12)	405,4
2-stage η = 75 %
13,7	12 (18)	25 (37)	109,5
25	12 (18)	25 (37)	60,0
3-stage η = 70 %
50,9	25 (37)	50 (75)	29,5	2,14	3,21	4,28	6,41
58,9			25,5	2,47	3,71	4,95	7,42
68,1			22,0	2,86	4,29	5,72	8,58
92,7			16,2	3,89	5,84	7,79	11,68
107,2			14,0	4,50	6,75	9,00	13,51
129,6			11,6	5,44	8,16	10,89	16,33
168,9			8,9	7,09	10,64	14,19	21,28
236,1			6,4	9,92	14,87	19,83	29,75
307,6			4,9	12,92	19,38	25,84	38,76

Output data: ROTECT with ROSYNC (energy-saving motor)

OUTPUT DATA STAINLESS STEEL MOTOR ROTECT WITH ROSYNC

Translation of	Permissible torque (peak)		Speed	Torque of the 1 ~ motor types		Torque of the 3 ~ motor types
i	Type P	Type R	1/min	44	84	44	84
i	Nm	Nm	1/min	Nm	Nm	Nm	Nm
Operating mode				S3 50 %	S3 33 %	S3 50 %	S3 33 %
1-stage η = 80 %
3,7	4 (6)	8 (12)	405,4	0,38	0,68	0,95	1,6
2-stage η = 75 %
13,7	12 (18)	25 (37)	109,5	1,34	2,36	3,29	5,55
25	12 (18)	25 (37)	60,0	2,44	4,31	6,00	10,13
3-stage η = 70 %
50,9	25 (37)	50 (75)	29,5	4,63	8,19	11,40	19,24
58,9			25,5	5,36	9,48	13,19	22,26
68,1			22,0	6,20	10,96	15,25	25,74
92,7			16,2	8,44	14,92	20,76	35,04
107,2			14,0	9,76	17,26	24,01	40,52
129,6			11,6	11,79	20,87	29,03	48,99
168,9			8,9	15,37	27,19	37,83	63,84
236,1			6,4	21,49	38,01	52,89	89,25
307,6			4,9	27,99	49,52	68,90	116,27

Depending on the application, a higher operating mode is also possible. The gearbox may be damaged if the permissible torque is exceeded. Other gear ratios available on request.

Output data: ROTECT with ROMOTION (BLDC motor)

OUTPUT DATA STAINLESS STEEL MOTOR ROTECT WITH ROMOTION

Translation of	Permissible torque (peak)		Rated speed - Rated torque
i	Type P	Type R	ROMOTION 44.2		ROMOTION 84.2		ROMOTION 84.4
i	Nm	Nm	1/min	Nm	1/min	Nm	1/min	Nm
1-stage η = 80 %
3,7	4 (6)	8 (12)	837,8	0,74	837,8	1,01	864,9	1,15
2-stage η = 75 %
13,7	12 (18)	25 (37)	226,3	2,57	226,3	3,49	233,6	4,01
25	12 (18)	25 (37)	124,0	4,69	124,0	6,38	128,0	7,31
3-stage η = 70 %
50,9	25 (37)	50 (75)	60,9	8,91	60,9	12,11	62,9	13,90
58,9			52,6	10,31	52,6	14,02	54,3	16,08
68,1			45,5	11,92	45,5	16,21	47,0	18,59
92,7			33,4	16,22	33,4	22,06	34,5	25,31
107,2			28,9	18,76	28,9	25,51	29,9	29,27
129,6			23,9	22,68	23,9	30,84	24,7	35,38
168,9			18,4	29,56	18,4	40,20	18,9	46,11
236,1			13,1	41,32	13,1	56,19	13,6	64,46
307,6			10,1	53,83	10,1	73,21	10,4	83,97

The operating mode must be checked in each individual case. The gearbox may be damaged if the permissible torque is exceeded. Other gear ratios available on request.

Output data: ROTECT with ROSLYDE (low-noise motor)

OUTPUT DATA STAINLESS STEEL MOTOR ROTECT WITH ROSYNC

Translation of	Permissible torque (peak)		Speed	Torque of the 1 ~ motor types		Torque of the 3 ~ motor types
i	Type P	Type R	1/min	44	84	44	84
i	Nm	Nm	1/min	Nm	Nm	Nm	Nm
Operating mode				S1	S3 50 %	S1	S3 75 %
1-stage η = 80 %
3,7	4 (6)	8 (12)	405,4	0,21	0,41	0,38	0,7
2-stage η = 75 %
13,7	12 (18)	25 (37)	109,5	0,72	1,44	1,34	2,67
25	12 (18)	25 (37)	60,0	1,31	2,63	2,44	4,88
3-stage η = 70 %
50,9	25 (37)	50 (75)	29,5	2,49	4,99	4,63	9,26
58,9			25,5	2,89	5,77	5,36	10,72
68,1			22,0	3,34	6,67	6,20	12,39
92,7			16,2	4,54	9,08	8,44	16,87
107,2			14,0	5,25	10,51	9,76	19,51
129,6			11,6	6,35	12,70	11,79	23,59
168,9			8,9	8,28	16,55	15,37	30,74
236,1			6,4	11,57	23,14	21,49	42,97
307,6			4,9	15,07	30,14	27,99	55,98

Depending on the application, a higher operating mode is also possible. The gearbox may be damaged if the permissible torque is exceeded. Other gear ratios available on request.

	Length in mm			Weight in kg
Geared motor	1-stage	2-stage	3-stage	1-stage	2-stage	3-stage
Planetary gearbox P
Rotect 34 / 36	160	200	200	2,40	2,80	3,00
Rotect 44 / 46	160	200	200	2,60	3,00	3,20
Rotect 64 / 66	200	200	240	3,05	3,25	3,60
Rotect 84 / 86	240	240	240	3,60	3,80	4,00
Planetary gearbox R
Rotect 34 / 36	160	200	200	2,55	3,10	3,45
Rotect 44 / 46	160	200	200	2,75	3,30	3,65
Rotect 64 / 66	200	200	240	3,20	3,55	4,05
Rotect 84 / 86	240	240	240	3,75	4,10	4,45

Gearbox

ROTECT with planetary gearbox

Power density: High & permanently resilient
Construction: Robust & maintenance-free
Torque: 3 - 50 Nm
Translation (i): 4:1 - 308:1

Special solution
looking for?

Our modular system enables millions of customised variants. We realise special solutions exactly according to your requirements and also manufacture in small series.

You want to assemble the components yourself?

No problem.

From the practice

Hygiene power in meat processing

In automated food processing, the ROTECT reliably sorts out contaminants - even under the most aggressive cleaning conditions.

IP69K protection: Withstands daily high-pressure cleaning & aggressive agents.
Precise handling: 90° rotation in milliseconds for exact X-ray scans.
75 Nm peak torque: Full power for frozen or highly compact masses.
